Nissan HR16DE Engine Workshop Manual

Nissan 2009-2014 Z12 Repair Manual. This is a manual on the engine mechanics of this Nissan model. Contains instructions and data on repair procedures. Includes exploded views of engine components, engine block, and cylinder head.

• Home Page>>
• Nissan Micra K12 Full Factory Service Manual>>

Nissan Cube Z12 is the third generation of this car, equipped with HR engines, including the K9K diesel engine. It is front-wheel drive, driven by a 16-valve 4-cylinder timing chain drive and with a displacement of 1.5 liters, 1.6; and 1.8 l depending on the country or region of sale. The ignition order of these engines is 1-3-4-2, like the 1.5 liter K9K diesel engine.

• Vehicle: Cube, Kicks, Livina, Micra, Note, Qashqai, Sentra, Tiida, Wingroad,  Juke, Latio, Versa.
• Engine type: L4
• Fuel: Gasoline
• Engine series: HR16DE
• Fuel consumption: 6.7L combined cycle

In the Nissan group mechanics manuals, all data on adjustment and repair of engines belonging to this group are shown. In some cases, the manual provides assistance in diagnostics using a troubleshooting table.

This diagnostic table is compiled based on symptoms that can be detected in the vehicle's engine. The troubleshooting table is dedicated to the mechanic conducting the process of checking each stepper motor system, providing data and specifications that need to be followed to eliminate a mechanical engine malfunction.

Simple and already studied design

No big problems with reliability

Available service and spare parts

Not the highest timing chain resource

May be difficult to start in cold weather

Hydraulic compensators are not provided
