Nissan KA24E Workshop Manual

Nissan 2.4L 1990 M11 KA24E Engine Repair Manual. This is a manual on the engine mechanics of this Nissan model. Contains instructions and data on repair procedures. Includes exploded views of engine components, engine block, and cylinder head.

Nissan Axxess 2.4L 1990 release. This car had a 2.4-liter 4-cylinder engine (2389 cc). The Prairie model came with optional all-wheel drive and a 2.0-liter engine. the drive of which was carried out through a timing chain and one camshaft with 2 valves. It had the Nissan ECCS fuel system. The firing order of this engine was 1-3-4-2 and the power output was 98 kW (131 hp).

• Home Page>>

Vehicle Praire, Axxes, Stanza Wagon, Liberty, Multi, Terrano 2 (R20). Bluebird, 240SX

Engine type L4

Fuel Gasoline

Engine series: KA24E

The mechanical manuals of the Nissan group show all the data on adjustment and repair of engines belonging to this group. In some cases, the manual provides diagnostic assistance using a troubleshooting chart.

This diagnostic table is compiled based on the symptoms that can be found in a car engine. The Troubleshooting Chart walks an auto mechanic through the inspection process of each stepper motor system, providing the data and specifications that must be followed to resolve a motor's mechanical problem.

• Most often, owners complain about very high fuel consumption or oil consumption
• The valves have to be periodically adjusted, since there are no hydraulic compensators
• The engine pan is easily wrinkled from an impact, which can lead to blocking of the oil receiver
• Closer to 250,000 km, it is often necessary to replace the timing chain or its tensioner
• The power unit does not like cheap oil; with it it cokes very quickly
