Nissan Sentra B17 2013-2019 Wiring Diagram

Nissan Sentra B17 2013-2019 Wiring Diagram is a detailed guide to the vehicle's electrical system. The diagram includes key components such as the battery, alternator, fuse box, engine sensors, and electrical equipment. The diagram shows how the various components are connected to each other, making it easier to diagnose faults and make repairs. It is an essential service tool that allows electricians and vehicle owners to effectively solve electrical system problems.

• Home Page>>
• Nissan Sentra (B17, 2013-2019) Service Manual>>
• Nissan Sentra B17 Error Codes List>>

1. Fuse box malfunctions

Description: Poor connections or oxidation in the fuse box can cause malfunctions in various systems.

Solution: Regularly check and clean the fuse box, replace blown fuses.

2. Problems with engine sensors (MAF, O2, etc.)

Description: Electrical malfunctions in the mass air flow (MAF), oxygen (O2), crankshaft position sensors can cause engine errors and reduce performance.

Solution: Diagnose with an OBD-II scanner, check and replace faulty sensors.

3. Lighting system malfunctions

Description: Often there are problems with headlights, taillights or turn signals due to faulty wiring or poor contacts.

Solution: Check the wiring, connectors and replace damaged areas.

4. Starter and Alternator Malfunctions

Description: Problems with the wiring leading to the starter or alternator can cause difficulty starting the engine or a rapid discharge of the battery.

Solution: Check the wiring for damage, loose connections or corrosion, replace faulty components.

5. Intermittent Multimedia System Operation

Description: Often, owners report malfunctions in the multimedia system, including freezing or no sound.

Solution: Restart the system, check the wiring and connectors, update the multimedia software.

6. Battery and Charging

Description: Charging problems or a sudden discharge of the battery can be caused by poor connections or faults in the charging circuit.

Solution: Check the condition of the battery, wiring, clean the terminals from corrosion.

7. Loose Connections and Grounding

Description: Poor grounding or loose connectors can cause malfunctions in various vehicle systems.

Solution: Regularly check and tighten all main connections and ground points.

8. Problems with the electric windows and doors

Description: Electric windows or door locks may stop working due to damage to the wiring in the doors.

Solution: Check the wiring in the door connectors for breaks or damage.
